High Voltage DC power Supply

About High Voltage DC power Supply

Product Specifications:

• Input Voltage : 230 V AC 10%
• Input Current : 2 A
• Out Put Voltage : 20 VDC to 2000 VDC Open Load
• Output voltage setting : Through rotary knob
• Output current Limit : 150 mA
• Output Protection : Over current, short circuit Trip through input
• mains , recover through reset switch
• Output Readout : 3 digit Voltage & current
• Input ON/OFF : Through MCB
• Output ON/OFF : Through Rocker Switch
• Input Fuse Rating : 2 A
• Output Terminals : Isolated Banana Socket (Female, RED and black)
• Output cable : 3 meter 2 Nos. cable for positive & negative
• Input Connection : Through 15A Rated Mains cord.
• Input ground side cable : 2 Meter Green single core wire.
• Cooling : Force air cooled
• Power Supply dimension : 300 mm x 150 mm x 510 mm ( W x H x D )
